Case Studies

Robust 12V DC Spur Gear Motors with a custom output shaft for a demanding commercial kitchen appliance.

A complete planetary gear motor assembly with lead wires, M12 connector and fast-on style connectors for a pharmacy automation vending machine.

Right angle gear motor with custom shaft and lead wires for residential elevator door actuator.

Compact and powerful planetary gear motor designed for robust medical and surgical devices.

Precision mini servo motors for a single-use medical dispensing device.

High torque customized bldc planetary gear motor solutions designed for automated roller shades.

A high torque and high speed, 12VDC planetary gear motor, designed to operate a unique piece of sporting equipment.

A 12VDC input ballast for 425mA lamps designed for Water purification applications.

A custom ballast with integrated UV-C lamp socket for 425mA lamps used for residential HVAC Air Purification systems.

Wearable Wrist and Finger Electrodes with an improved design and comfort. These proved to be highly reliable and passed the rigorous FDA requirements.

A unique vertically oriented switching power supply with a customized barrel connector.

This is an example of how ISL Products can take a standard Stepper Motor and tweak it to perform exactly how you need it to in your application.

A highly reliable spur gear motor that we customized to meet our customer's requirements. We were able to customize a standard spur gear motor to avoid expensive tooling.

ISL replicated a very particular 90ohm speaker, about the size of a dime, that had gone end-of-life.

ISL was tasked with reverse engineering and manufacturing two different sockets that are used in proprietary nurse call systems around the world.

SMT Dynamic Speakers that ISL manufactured to prevent a Fortune 500 customer from having to do a full redesign of their product.

ISL used its value-added capabilities to improve a standard potentiometer so it could be safely used on deep fryers by world-leading fast-food restaurants.

A piezoelectric loudspeaker without any magnetics that can be used in virtually any environment. It provides excellent voice reproduction and operates at a broad frequency range.

We teamed up with a group of scientists at Case Western Reserve University to help develop a medical-grade cable assembly to help restore movement in patients who suffered spinal cord injuries.

Handlebar-mounted motorcycle speakers that ISL manufactured for an industry leader. From the chrome-plated housing to the 55mm speaker inside, ISL manufactured it all and delivered a completed speaker assembly to the…

Two versions of a custom connector that ISL manufactured for a customer who needed both a Stereo and Mono type 3.5mm plug to mold onto his cable assembly.

ISL developed a DC spur gear motor that drew 25% less current than the customer's incumbent motor. The ISL motor was also a direct drop-in replacement for the customer's application.

A glow in the dark keypad that does not require backlighting. This keypad has multiple glowing colors that meet the customer's specific glow time requirements. The keypad is used in an…

A customer approached us due to high failure rates from an incumbent ballast. We were tasked with designing a similar ballast that would operate standard UV-C lamps at 425mA in commercial HVAC…

Custom DC Motor Assemblies that are used in a variety of high security electronic locks by one of the largest security companies in the world.

A complete DC Gear Motor Assembly. ISL delivered a complete drop-in assembly to help speed up the customer's assembly process.

This AST transformer takes in 1.5V from a coin battery and produces 20V minimum output, to drive a Piezo alarm loud enough to deter theft.

A 9V Battery Charger designed to be used specifically with T.E.N.S machines. Its slim line profile and unique case make it easy to use.
