DC Motor and DC Gear Motor Selection Tips
4 Tips For Selecting a DC Motor or Gear Motor For Any Application
How to select a DC motor for a particular application?
There are a few things to consider when it comes to the motor selection process. We all know that electric motors convert electrical energy into mechanical energy, but there are a lot of options on the market to choose from. The motor selection process can be a daunting process: we are here to help get you focused and headed in the right direction with our 4 Motor Selection Tips.
As world-leading DC Motor and Gear Motor design experts, we are here to get your next project “moving”. Our team of dedicated application engineers can assist and answer any questions you may have, just use the live chat feature below to get in touch or give us a call.
Tip # 1: Determine Your Speed, Torque and Voltage First
The three main specifications you will need to know for any DC motor application are voltage, speed and torque. Once these aspects are determined, you are now ready to get started on your journey to select the ideal motor solution. The key is to use a motor that is operating at or near its maximum efficiency.
Motor voltage should also be defined at the start of the motor selection process. Motor voltage will be determined by your electrical power source, for example a 12-Volt battery or power supply.The nominal voltage for DC motors is typically either 12 or 24VDC.
Rotational speed is important for any motion control application. The rated or on-load motor speed is how fast a DC motor will operate once a load is applied. The constant speed and maximum speed that the motor needs to operate at are important to know.
Motor torque is the amount of load the motor’s output shaft can overcome at a given point. The torque and speed of a motor are directly related to one another, as one increases the other decreases. The rated torque, or on-load torque, needs to be defined just like the speed. Another important aspect of torque is the motor’s stall torque or peak torque.
The relationship between torque and speed can be best understood by evaluating a motor’s performance curve, commonly found with the motor specification.
Choosing a motor or gear motor that meets both your speed and torque requirements is crucial in selecting an efficient motor for your application.
Tip # 2: Balance Size vs. Performance
Proper motor size is important for every application but it can become an issue if a certain performance is required. Typically, larger motors are more powerful than their smaller counterparts. Depending on your application requirements, you may have to sacrifice certain performance characteristics to help accommodate the size constraints.
By utilizing different types of motors and motor technologies, like brushless motors or motors with permanent magnets, there are endless possibilities to help meet the size constraints for the majority of applications.
Tip # 3: Gear Motors Offer More Torque
Sometimes you need more torque than is physically possible to get out of a standard DC motor. Utilizing a DC gear motor will result in increased torque and reduced speed, which is all dependent on the gear ratio that is used. There are 3 basic types of gear motors: spur gear motors, planetary gear motors, and worm gear motors. Each gearhead type has its own distinct advantages.
You can add a gearhead to stepper motors, brushless DC motors, as well as brushed DC motors. To learn more about the distinct differences between the different gear motor types, check out our design note: Planetary Gear Motors Vs. Spur Gear Motors.
Tip # 4: Define your Duty Cycle
Your duty cycle will dictate which motor type is best for your application or device. Operating times and dwell times, as well as directional rotation, are key aspects of your duty cycle. The duty cycle should be defined at the beginning of the motor selection process.
Intermittent duty cycles are encouraged for most industrial applications to help extend the useful life of a motor or gear motor. Continuous use is still acceptable but you need to make sure the motor is operating at its peak efficiency.
